加工能力Processing capacity

DHD-800

DHD-1200

DHD-1600

DH-2000

主轴数Spindle number

单轴

单轴

单轴

单轴

转孔直径Borehole diameter

3-30mm

3-30mm

3-30mm

3-30mm

转孔深度Drilling depth

800mm

1200mm

1600mm

2000mm

机床行程Machine tool travel

工作台左右行程(X轴)Work around Taiwan travel (X axis)

800mm

1050 mm

2100 mm

2300 mm

主轴上下行程（Y轴）The upper and lower travel (Y axis)

800 mm

1040 mm

1300 mm

1300 mm

主轴左右行程(Z轴) Spindle and travel (axis)

830 mm

1230 mm

1650 mm

2050 mm

机床功率Machine power

主轴电机Spindle motor

7.5kw

7.5kw

7.5kw

7.5kw

X轴电机x axis motor

2kw

2 kw

2.9 kw

2.9 kw

Y轴电机y axis motor

2 kw

2 kw

2.9 kw

2.9 kw

Z轴电机z axis motor

1.3 kw

1.3 kw

1.3 kw

1.3 kw

高低压汞电机High and low pressure mercury mercury motor

11.2kw

11.2kw

11.2kw

11.2kw

机床总功率Machine total power

24kw

24kw

26kw

26kw

加工速度Processing speed

主轴最高转速Maximum speed of spindle

4500rpm

4500rpm

4500rpm

4500rpm

切削进给速度Cutting feed speed

1-150mm/min

1-150mm/min

1-150mm/min

1-150mm/min

工作台Bench

负重Load

7ton

9 ton

10 ton

12 ton

面积The measure 偶发area

900*650mm

1160*900 mm

2200*1400 mm

2400*1600 mm

机床冷却系统Machine cooling system

高低压汞压力范围High and low pressure mercury pressure range

2-100kg/cm²

2-100kg/cm²

2-100kg/cm²

2-100kg/cm²

出油量范围The oil out put range

6-42L/min

6-42L/min

6-42L/min

6-42L/min

机床尺寸Dimensions the machine

5600*3000*2550

6000*3300*2750

6500*5600*3000

6700*5800*3000

机床重量Weight of machine tool

6ton

8ton

15.5ton

17ton

标志配件Standard accessories

三轴日本伺服电机及驱动器Three axis servo motor and drive 台湾BT40 8000RPM主轴The Taiwan BT40 8000RPM spindle 切削油冷却系统Cutting oil cooling system

油压系统Hydraulic system排屑机Chip machine

枪转库Gun drill

高/低压汞Highlow pressure mercury

枪钻、导套各1件Gun drill, a guide sleeve 1pieces 工具箱Toolbox
